Automatic Block Making Machine Supplier

Automatic Block Making Machine Supplier
Details:
Dimension:5000 ×2450 ×2930mm
Weight:6T
Pallet size:880×680mm
Power:42.15 kW
Vibration method: Siemens motors
Cycle time 15-20s
Vibration Force 50-70KN
Send Inquiry
Chat Now
Download
Description
Technical Parameters

AUTOMATIC BLOCK MAKING MACHINE SUPPLIER

IFrame

Products Description

Our automatic block making machine is a high-efficiency, intelligent concrete product manufacturing equipment, which can produce hollow blocks, solid bricks, interlocking pavers, curbstone, grass bricks, drainage bricks and other concrete products. It is widely used in construction material factories, municipal engineering, road construction, landscaping and other fields.





Technical specification:



Dimension

5000×2450 ×2930mm

Weight

6T

Pallet size

880 ×680mm

Power

42.15 kW

Vibration method

Siemens motors

Vibration Frequency

3800-4500 r/min

Cycle time

15-20s

Vibration Force

50-70KN



Main features
automatic block making machine supplier
automatic block making machine supplier



The design philosophy of UNIK fully automatic block machine is: on the premise of ensuring stability, maximize the degree of automation and output per unit time. The company has focused on solving three technical problems: timing matching of the whole line linkage, optimization of vibration parameters under multiple raw material conditions, and data security of remote monitoring.

As of 2025, UNIK fully automatic block machines have been exported to more than 40 countries and regions around the world, widely used in residential construction, municipal engineering, commercial development, industrial plants and other types of projects. The company has passed ISO and CE certifications, and owns advanced manufacturing equipment such as CNC machining centers and large gantry milling machines.



Products

Pic

Size

Capacity

Cycle time

Daily capacity

Hollow block


390 ×190 ×190mm

5pcs/pallet

15-20s

7200pcs

Hollow brick


240 ×115 ×90mm

16pcs/pallet

15-20s

23040pcs

Brick


240 ×115 ×53mm

34pcs/pallet

15-20s

48960pcs

Paver


200 ×100 ×60mm

20pcs/pallet

15-20s

28800 pcs





Our factory.
automatic block making machine supplier

Manufacturing

automatic block making machine supplier

Delivery

automatic block making machine supplier

workshop

automatic block making machine supplier

Process

Order Information

Please provide the following details when placing an order:

  • Type and Specifications of Planned Products
  • Expected Daily Output
  • Raw Material Type (River sand / Manufactured sand / Stone powder / Recycled aggregates)
  • Power Supply Conditions (Voltage, frequency, and stability)
  • Site Area and Layout Requirements
  • Budget Range
  • Requirement for CE Certification & Remote Monitoring Function

UNIK Fully Automatic Block Making Machine

- From Raw Materials to Finished Products, One-Click Completion.
