China Hollow Block Making Machine
Unik machinery Co; ltd.
Our company is an enterprise integrating production, sales, scientific research and development. Our China hollow block making machine is a kind of mechanical equipment specially used to produce hollow blocks, which is widely used in the construction industry. It uses fly ash, construction waste, slag, river sand, gravel and other industrial wastes as raw materials, and produces by adding a small amount of cement, which is an environmentally friendly building materials equipment.
The main structure of the China hollow block making machine includes the distribution mechanism, frame, silo, pressure head, plate supply mechanism, lifting workbench, control cabinet and block conveyor and other parts.
This kind of equipment usually uses a combination of hydraulic transmission and mechanical transmission to manufacture hollow blocks through vibration pressure molding. Its working principle is to feed the raw materials into the mold, and through the action of vibration and pressure, the raw materials are closely arranged to form hollow blocks.
The China hollow block making machine has the characteristics of high degree of automation, high production efficiency and low labor intensity, which can realize the multi-purpose of one machine, and can produce hollow blocks of different specifications and shapes by replacing the mold.
Precision and Consistent Product Quality
China hollow block-making machines from our reputable brand are equipped with advanced technology that ensures precision and consistency in block production. This means every hollow block produced is of uniform size and quality, reducing the likelihood of errors and rework on the construction site. By choosing our block machine, companies can meet the demands of modern building solutions while maintaining a strong focus on cost management and efficiency.
The use of China hollow block making machine not only improves production efficiency, but also reduces production costs, and because the hollow blocks produced by it have the advantages of light weight, high strength, thermal insulation, etc., they have been widely used in the construction industry. In addition, the hollow block machine also has environmental protection characteristics, which can effectively use industrial waste and reduce environmental pollution.
High-quality and eco-friendly
We offer a variety of China hollow block making machines that use waste materials and industrial by-products as raw materials, such as coal gangue, fly ash, and construction waste. This not only reduces resource consumption but also realizes the recycling of waste, reduces production costs, and minimizes environmental pollution. With various models such as fully automatic, semi-automatic, and concrete hollow block making machines, we can meet the different investment needs of users.
one-stop solution
professional team
high quality
Products Parameters
|
Dimension |
3100×1680×2460mm |
|
Pallet Size |
850×680×20-35mm |
|
Vibration Frequency |
3800-5500 r/min |
|
Hydraulic Pressure |
25 mpa |
|
Vibration Force |
75 KN |
|
Cycle time |
15-20s |
|
Power |
41.53kW |
|
Weight |
7400KG |
|
Product size(mm) |
Pcs./Pallet |
Pcs./Hour |
|
390x190x190mm |
6 |
1080 |
|
240x115x90mm |
15 |
3600 |
|
200x100x60mm |
21 |
3024 |
|
240x115x53mm |
30 |
7200 |
Products Precautions
1. Regular cleaning and inspection: China hollow concrete block making machine should be kept clean frequently, remove the waste and oil stains on the machine, and scrub the appearance of the machine. When the machine is running, all protective covers and floor covers must be installed to ensure safe operation
2. Protection of the electrical part: The electrical part should be placed in a separate operation room to avoid short circuit caused by rain or moisture, causing equipment failure.
3. Maintenance of hydraulic system: check the hydraulic system of the block forming machine regularly, if there is any deterioration or excessive impurities of hydraulic oil, it needs to be filtered or replaced in time; When the hydraulic oil is too small, it should be added in time.
4. Lubrication of moving parts: Lubricating oil should be added regularly to the moving parts of the block forming machine to protect the columns, piston rods, etc. from wear and tear. Bearings should also be lubricated regularly to reduce the temperature during operation and to avoid dust ingress.
5. Daily inspection: every day to work needs to carry out an overall inspection of the block forming machine, and the phenomenon of oil leakage and loose screws should be dealt with in time to avoid small failures causing large losses.
