Twin shaft concrete mixer cement stand machine:
Twin shaft JS concrete mixer cement stand machine have two advantages: independent performance and forming simple concrete mixing plants with PLD series of batching machines. JS concrete mixers for sale have stronger mixing effect than that of self-falling concrete mixer, so JS concrete mixer are suitable to mix dry concrete and light weight aggregate concrete. when apply to concrete, materials are deliveryed to storage hopper of block machine, parameters can be set according to the humidity of material and the variety of aggregate.
| Technical Specification: |
JS500 | JS750 | JS1000 | ||
Rated discharging volume | 500L | 750L | 1000 L | |
Rated feeding volume | 800L | 1200L | 1600 L | |
Rated productivity | ≥25m3/h | ≥37.5m3/h | ≥50m3/h | |
Power of mixing motor | 18.5KW | 30KW | 37kW | |
Power of winch motor | 5.5KW | 7.5kW | 10kW | |
Power of water pump motor | 0.75kW | 1.1kW | 2.2kW | |
Discharging height | 1500mm | 1600mm | 1800mm | |
Dimension | Working state | 2600×3050×2100mm | 3320×2400×2600mm | 9700×3695×8460mm |
Transportation state | 3870×3050×5250mm | 3320×2400×4900mm | 4400×2230×2700mm | |
Weight | 4000kg | 6800kg | 10000kg | |
