A "specialist" for cellular blocks

There are many types of hollow blocks, and the most difficult to produce are cellular blocks – with many holes, thin walls, and dense partitions. These blocks are becoming increasingly popular in modern construction because they are lightweight and offer good thermal insulation. But they are also more challenging to produce: the mold cavity has a dozen or even dozens of holes, and the material needs to fill every corner simultaneously. If any hole is not fully filled, the resulting block is defective.

Traditional spreading methods pour all the material into the mold box at once, relying on vibration to level it out naturally. For complex structures like cellular blocks, this method is far from sufficient – the material tends to pile up, bridge over the holes, and fail to fill corners.

The core design logic of the QT6-15 is optimization specifically for this problem.

Control system: PLC fully automatic, Mitsubishi/Siemens optional

The entire production process of the QT6-15 is managed by a PLC control system. The operating system uses a Mitsubishi programmable logic controller (PLC) and a human‑machine interface touchscreen, equipped with data input devices, safety logic control, and a fault diagnosis system, enabling ideal human‑machine interaction. It supports manual, semi‑automatic, and fully automatic operating modes, with parameters for each actuator being freely adjustable.

Products	Pic	Size	Capacity	Cycle time	Daily capacity
Hollow block		390 ×190 ×190mm	5pcs/pallet	15-20s	7200pcs
Hollow brick		240 ×115 ×90mm	16pcs/pallet	15-20s	23040pcs
Brick		240 ×115 ×53mm	34pcs/pallet	15-20s	48960pcs
Paver		200 ×100 ×60mm	20pcs/pallet	15-20s	28800 pcs

Main functions of the control system:

The control system is equipped with comprehensive logic control, production programs, fault diagnosis, and remote control functions. It can be operated via a computer interface, enabling random signal analysis, fault diagnosis, and parameter setting to ensure optimal machine performance. The powerful memory allows for future upgrades. No professional operators are required – only simple training is needed.
