China Paving Block Making Machine


A paving brick machine (also known as a block paver machine, or colored brick machine) is a specialized forming machine specifically designed for producing concrete paving bricks, permeable pavers, interlocking blocks, curbstones, and other paving materials.

Using hydraulic or mechanical vibration forming principles, the machine processes raw materials such as cement, sand, and crushed stone through batching, spreading, vibration, pressing, and demolding – forming them into high‑density concrete paving bricks in a single cycle. When a fully automatic production line is adopted, the entire process from batching to finished product palletizing can be fully automated.

  High‑strength frame structure
The frame is manufactured using extra‑large high‑strength steel sections and special welding techniques, offering good rigidity, vibration resistance, and a long service life. Four guide columns with extra‑long guide sleeves ensure operational accuracy. Vibration‑damping rubber is used at critical points to reduce vibration impact and extend the overall machine life.

 Advanced vibration forming system
The machine employs various vibration methods, including table vibration, mold vibration, and table‑mold resonance vibration, providing high exciting force. Some models use servo frequency conversion technology to control vibration, and the vibration exciter assembly features an oil‑immersed design. The vibration platform combines dynamic and static actions, allowing the concrete to fully liquefy and release air in an instant, resulting in more standardized product dimensions. A unique vibration isolation system concentrates the exciting force on the mold, ensuring block density while reducing frame vibration and noise.

Products	Pic	Size	Capacity	Cycle time	Daily capacity
Hollow block		390 ×190 ×190mm	5pcs/pallet	15-20s	7200pcs
Hollow brick		240 ×115 ×90mm	16pcs/pallet	15-20s	23040pcs
Brick		240 ×115 ×53mm	34pcs/pallet	15-20s	48960pcs
Paver		200 ×100 ×60mm	20pcs/pallet	15-20s	28800 pcs

One machine, multiple uses – a wide range of products
By changing molds, the same machine can produce hollow bricks, solid bricks, colored paving bricks, interlocking bricks, curbstones, grass planting pavers, slope protection bricks, and more. Some models are equipped with a secondary spreading mechanism, allowing the production of two‑tone or multi‑colored paving bricks and imitation stone bricks.

Flexible investment, fast return
Equipment prices range from tens of thousands to over a million yuan, covering everything from small manual machines to large fully automatic production lines. Raw materials such as fly ash, slag, construction waste, and other industrial by‑products can be used to replace natural sand and gravel, significantly reducing production costs.
