Concrete Block Moulding Machine for Sale
The block moulding machine uses stone powder, sand, stones, slag, slag, fly ash, cement, etc. as raw materials for brick making. After scientific proportioning, can produce cement bricks, hollow blocks, colored bricks, and tiles.
Technical specifications:
Main Dimension(L*W*H) | 3400*2100*2580mm |
Useful Moulding Area | 1000*600*40~220mm |
Pallet size (L*W*H) | 1100*740*25~30mm |
Pressure Rating | 12~25Mpa |
Vibration | 60~95KN |
Vibration Frequency | 2800~4800r/min |
Cycle time | 13-18s |
Power | 42.15kW |
Gross weight | 10.5T |
Complete line of equipment:
1.Block making machine 2. Batching and mixing plant 3. Automatic stacker 4.PLC control system 5.Automatic cubing system 6. Pallets feeding machine
Main features:
1. It can be customized to produce products with a height of 400mm, which is suitable for the production of large-scale products, and the production of large-scale hydraulic slope protection and curbstones.
2. It can be produced vertically and can choose layered fabrics, the output is increased, and the appearance of the product is better.
3. The forced centrifugal feeding system prevents the concrete from liquefying in advance, and the mechanism work produces forced centrifugal unloading, so that the materials are ready for use and the cloth is fast and even.
4. The four-axis synchronous vibration system integrates multiple technologies such as computer control, Schneider frequency conversion system, and motor drive control.
5. The control appliances are all international brands such as Fuji, Siemens, ABB, Schneider, etc., and the quality is guaranteed.
6. The reinforced vibration system with a 25% increase has a good vibration effect for ultra-high products.
Product size | Picture | Capacity |
400×200×200(mm) |  | 8 pcs/pallet |
| 1350 pcs/hour | ||
225×112×60/80mm |  | 24 pcs/pallet |
| 4800 pcs/hour | ||
200×100×60/80(mm) |  | 30 pcs/pallet |
| 7200 pcs/hour | ||
447×298×80/100(mm) |  | 2 pcs/pallet |
| 480 pcs/hour | ||
Pallet size | 1100×740㎜ | |
Vibration type | Frequency, amplitude | |
Excitation frequency | 0～65HZ | |
Power | 42.15 kW | |
Our service:
Before sale:
(1) Selection of equipment model.
(2) Design and manufacture products according to customers' special requirements.
(3) Train technical personnel for customers.
(4) The company sends engineering and technical personnel to the user site free of charge to plan the site and design the best process and plan for the user.
On sale:
(1) Product acceptance.
(2) Assist customers in drawing up construction plans.
After sale:
(1) Freely assign dedicated after-sales service personnel to arrive on-site to guide customers in installation and commissioning.
(2) Equipment installation and debugging.
(3) On-site training of operators.
(4) After the complete set of equipment is installed, 1-2 full-time technicians will be left to assist the customer in on-site production for free until the customer is satisfied.
FAQ:
1. Is this block machine suitable for us to use?
Could you please tell us what kind of bricks do you want to make? And the capacity you want? Let us check if it can meet your request.
2.Which industry did this block machine usually be used in?
Interlocking bricks, Hollow bricks, Paving bricks,Solid bricks,etc
3.How to use the block machine?
We will send the operating manual to you after you purchase the machine, for bigger machine, we can offer engineer fly to your side for installation and training your workers.
4.How about the after sale service of block machine?
we promise 12 months guarantee for date of purchase, and agrees to repair or replace any defective part without charge,This warranty does not cover in cases of improper user, incorrect handling, insufficient maintenance, act of third parties, unauthorized service or modifications to the machine, damage resulting from accident, abuse, lack of reasonable care, normal wear or the addition of any other equipment not provided with product
5.what's your payment term
our common payment is 30% deposit by T/T before arrange the machine production,70% balance before the delivery,if other payment term,we can negotiation.
