Block Machine Price
Our solid block Making Machine is based on the principle of hydraulic machine. It is mainly used in the molding process. It uses hydraulic oil as the working medium to complete the operation of the brick machine without any waste,mainly composed of a main machine, a hydraulic pump station, a electric control system and pallets&blocks conveyor.It is capable of producing interlocking paving stones,turf stones,ornamental stones,edge stones,curb stones,full stones,hollow blocks,slabs and similar concrete products.This machine fulfils all necessary requirements to produce concrete products of the highest quality.
| Main Features: |
|
|
| The well-know imported brand integrated and independent hydraulic valves | The vibration system of the machine is equipped with our standard frequency controlled vibration system which is creating a uniform vertical vibration. |
|
|
| The machine frame consists of a welded construction using sectional steel to ensure optimum rigidity and accessibility. | Helical Bevel Gear Reducer:Good meshing performance,Heavy coincidence and Compact structure |
| Specification&Capacity |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
Capacity | ||
Product size(mm) | Pcs./Pallet | Pcs./Hour |
390*190*190 | 8 | 1440 |
390*140*190 | 8 | 1440 |
200*100*60 | 27 | 3888 |
225*112.5*60 | 20 | 2880 |
Our factory specializes in the production and sales of various types of cement brick machine equipment. It can also provide equipment installation and commissioning, technical guidance, technical personnel training and other related services. The advantages of this equipment are small investment, high return, and the ability to change molds at will. It is an ideal choice for small and medium-sized cement products manufacturers who produce medium square pavers and small blocks.
Block mould technical specifications:
1. Different parts of the mold are made of different high-quality steels, and the key parts are made of cast steel and infiltrated with a certain amount of manganese steel.
2. In the same set of molds, different heat treatment methods are used according to different requirements, (mainly CNC nitriding Technology, carburizing technology, carbonitriding technology, high-frequency quenching technology, etc.)
3. The design structure combines the advantages of others, adopts a unique lower mold mutual clamping connection, and a non-welded connection between the mold and the hanging beam.
4. The use of wire Cutting method processing, so that the upper and lower unilateral gaps of the mold: the floor tiles are reduced by 0.3-0.4mm, and the blocks are 0.6-1mm.
5. The comprehensive heat treatment process makes the mold's service life longer
Our service:
(1) Analyze the current investment-free brick machine investment market for customers and provide real investment solutions.
(2) Let customers know in detail the links of the block machine industry.
(3) Tailor-made high-quality brick machine equipment for customers.
(4) Plant planning and design, water consumption, and electricity consumption planning.
(5) Send a professional to install the brick machine and debug it.
(6) Recommend professional operators for customers.
(7) Can assist companies in training employees.
(8) Introduce high quality raw material suppliers to enterprises.
UNIK has set up a dedicated service center and established a high-quality technical service team to achieve rapid response, customer return visits, technical consultation, staff training, long-term supply of spare parts, guaranteed value-added services.
