AUTOMATIC BLOCK MACHINE PRICE
Products Description
A fully automatic block machine is a full-process automatic concrete forming equipment covering raw material batching, mixing, molding, pressing and automatic brick discharging. Unlike semi-automatic models, it requires no manual intervention in core production procedures; operators only need to monitor the machine and perform auxiliary work.
Technical specification:
|
Dimension |
5000×2450 ×2930mm |
|
Weight |
6T |
|
Pallet size |
880 ×680mm |
|
Power |
42.15 kW |
|
Vibration method |
Siemens motors |
|
Vibration Frequency |
3800-4500 r/min |
|
Cycle time |
15-20s |
|
Vibration Force |
50-70KN |
Main features
High-frequency Variable Frequency Vibration & Strong Raw Material Adaptability
The vibration system adopts variable frequency control, with adjustable vibration frequency from 45 to 70Hz and exciting force ranging from 0 to 80kN. It can match the optimal vibration parameters for river sand, manufactured sand, stone powder and recycled aggregates.
The vibration motor is equipped with imported heavy-duty bearings, whose service life is more than three times that of ordinary bearings. The dual vibration isolation design of rubber damping pads and springs reduces vibration transmission and extends the service life of the equipment.
|
Products |
Pic |
Size |
Capacity |
Cycle time |
Daily capacity |
|
Hollow block |
|
390 ×190 ×190mm |
5pcs/pallet |
15-20s |
7200pcs |
|
Hollow brick |
|
240 ×115 ×90mm |
16pcs/pallet |
15-20s |
23040pcs |
|
Brick |
|
240 ×115 ×53mm |
34pcs/pallet |
15-20s |
48960pcs |
|
Paver |
|
200 ×100 ×60mm |
20pcs/pallet |
15-20s |
28800 pcs |
Our factory.
Manufacturing
Delivery
workshop
Process
The Value of Full-Automatic Operation
Labor Cost Reduction: A full-automatic production line only requires 1 to 2 operators, cutting labor costs by over 50% compared with semi-automatic lines. Calculated at a monthly salary of $300 per worker, the annual labor cost savings exceed $5,000.
Stable Product Consistency: Manual operation is affected by fatigue, mood and proficiency, leading to severe quality fluctuations. Full-automatic equipment runs according to preset parameters, ensuring excellent consistency for every batch of products and meeting project acceptance standards.
Higher Equipment Utilization: Semi-automatic equipment is limited by manual efficiency with restricted actual operating hours. Full-automatic machines support continuous operation, boosting equipment utilization by more than 30%.
Traceable Production Data: Full-automatic equipment automatically records production data, complying with the quality traceability requirements for building materials in government projects and large-scale engineering works. Exported data can be used as quality certification for project acceptance.
