Automatic Board Feeder

Automatic board feeder The advantage automatic board feeder is that it does not require a special equipment basis, and can be placed on a hardened flat surface to be used in connection with the pallet conveyor. This reduces the labor intensity of the operator, improves the work efficiency, saves...

Details

Automatic board feeder



The advantage automatic board feeder is that it does not require a special equipment basis, and can be placed on a hardened flat surface to be used in connection with the pallet conveyor. This reduces the labor intensity of the operator, improves the work efficiency, saves labor, and reduces production costs. The entire machine has no moving cables and electrical components. , ensure the personal safety of the operator; overall equipment has a simple and reasonable structure, operation and use of flexible, reliable performance, wide range of applications.

The machine only needs to use a forklift and a hydraulic transfer vehicle to place the stacked 20-30 pallets on the upper board rack. The machine can automatically complete the entire process of board loading, lifting, and board feeding.

The automatic board feeder machine can be completely operated without special personnel. In the case of increasing labor costs, it saves 1-2 employees' expenses in the factory, so it has higher economic benefits.
It is easy to install, it is on the side of the machine board, but also on the rear board. There is no need to make a separate foundation, and no pre-embedded parts can be installed on the existing cement floor for half a day.



Technical specification:

Items

Specification

Dimension

2800×2500×2500 mm

Suitable Pallets Size

850x680—880x1440mm

Pallets Quantity

25-30pcs

Hydraulic Pressure

14-20mpa

Bearing Weight

3000kg

Bearing height

1000mm

Pneumatic Pressure

0.5-0.8kpa

Power

5.5kW

 Automatic board feeder.jpg

well-known brand parts.jpg
